Standing Seam with Nail Flange
Standing Seam with Nail Flange is a 24-gauge Grade 50 Galvalume hidden-fastener metal roofing panel. Installation uses a nail flange that attaches to the roof deck, keeping all fasteners out of sight and off the weather face. It shares the same gauge, grade, colors, and trim line as the Snap Lock profile — the main difference is how it handles thermal movement. Nail Flange is best suited for panel runs up to 16 feet where thermal expansion stress is manageable.
Technical Specifications
| Property | Value |
|---|---|
| Gauge | 24 gauge |
| Steel Grade | Grade 50 (softer, for sharp bends) |
| Substrate | AZ50 Galvalume |
| Panel Coverage | 16 inches (1.33 sq ft/lf) |
| Fastener Type | Nail flange (hidden) |
| Substructure | 1/2" or 5/8" plywood (recommended); or purlins 16" OC |
| Best For | Panel runs up to 16 feet |
| Paint System | Kynar |
| Warranty | Kynar Paint + Red Dot Galvalume |
About This Profile
Standing Seam with Nail Flange is the traditional standing seam approach, using a nail flange attachment. It shares the same colors, 24 gauge Galvalume, and trim line as our Snap Lock profile. Because a nail flange locks the panel down more rigidly, it's generally recommended for shorter panel runs of 16 feet and under.
Key Features
- ✓Nail flange attachment — concealed fastener system
- ✓Traditional standing seam profile
- ✓Recommended for shorter runs, 16' and under
- ✓16" wide coverage per panel
- ✓Contractor-friendly installation
- ✓Same colors & trim as Snap Lock Standing Seam
Best For
- →Shorter panel runs (16' and under)
- →New residential construction
- →Re-roofing projects
- →Gable roofs & conventional layouts
Panel Profile
What this panel actually looks like in cross-section — including how it's fastened.
The fastening system is the difference: a nail flange extending from the seam base is fastened directly to the deck with exposed screws, then covered by the next panel. Same 16"-wide standing seam look as Snap Lock, optimized for runs 16' and under.
Available Colors
This exact color palette is shared by both Snap Lock Standing Seam and Standing Seam with Nail Flange.
Same colors and trim as Snap Lock Standing Seam. Free metal samples available for 100% color matching.
Trim Options
Every trim piece is fabricated to your exact specifications in matching panel colors — not a generic off-the-shelf approximation. This trim line is shared by both standing seam profiles.
Related Standing Seam Profiles
Warranty Coverage
- ✓25-Year Galvalume metal warranty — the metal itself, on every profile.
- ✓40-Year Kynar Paint Warranty — Standing seam is formed with sharper bends, so it uses a more flexible Sherwin-Williams Kynar paint film — which carries its own warranty.
Frequently Asked Questions
What gauge is Standing Seam with Nail Flange?
24-gauge Grade 50 Galvalume. The same gauge and grade as Snap Lock Standing Seam — Grade 50 is used because standing seam's tight forming bends require softer, more ductile steel.
What is the maximum panel length for Nail Flange standing seam?
16 feet. Beyond that, the fixed nail flange can't accommodate the thermal expansion and contraction of longer panels effectively. For runs over 16 feet, Snap Lock Standing Seam with its floating clip system is the right choice.
How wide does Standing Seam with Nail Flange cover?
Each panel covers 16 inches of width — 1 linear foot equals 1.33 square feet of coverage.
What is the difference between Nail Flange and Snap Lock standing seam?
The fastening method. Nail Flange has an exposed flange that's screwed directly to the deck, then covered by the adjoining panel — a faster install for experienced crews on shorter runs. Snap Lock uses a hidden clip that allows independent thermal movement, making it better suited for longer panel runs (over 16 feet).
What substructure does Nail Flange standing seam require?
1/2" or 5/8" plywood sheathing is recommended. Purlins at 16" on center are an acceptable alternative.
What warranty comes with Standing Seam Nail Flange?
A 40-year Kynar paint warranty and a 25-year Red Dot Galvalume metal warranty — the same coverage as Snap Lock Standing Seam.
